China GR7 Ti-0.2Pd Titanium rods Supplier, Suppliers

Grade: Grade7(Ti-0.2Pd)

Standards: ASTM B348

Specifications: Î¦5-100mm*L2000-3000mm

Supply Surface:Â Polished Surface,Lathe Machined Surfaces,black oxidized surface

For other lengths and diameters, production cuts can be made on request.

Send Inquiry

Product Description

⚙️ Technical Parameters

Chemical Composition & Mechanical Properties for Grade 7 Titanium Rod

Grade	Chemical Composition (%)								Mechanical Properties
Grade	Pd	Fe	C	N	H	O	Each	Total	Tensile Strength	Yield Strength	Elongation (50mm %)	Reduction of Area Z / %
GR7	0.2-0.25	≤0.30	≤0.08	≤0.03	≤0.015	≤0.25	≤0.10	≤0.40	≥370	≥250	≥20	≥25

🚀 Performance Features

🛡️

Corrosion Resistance

GR7 titanium alloy offers exceptional corrosion resistance in both oxidizing and reducing media, particularly in high chloride environments to prevent crevice corrosion.

Example: Significant corrosion rate reduction in 5% boiling sulphuric acid.

🛠️

Excellent Machinability

Features superior machining, forming, and welding performance, suitable for complex structural components.

Example: Highly suitable for secondary CNC precision machining with stable performance.

🏭 Industry Applications

GR7 Titanium rods for corrosion resistant chemical applications are widely utilized in manufacturing equipment for highly corrosive environments. Due to its unique material properties, it is the preferred choice for:

• Reactors & Towers
• Autoclaves
• Heat Exchangers
• Pumps & Valves

• Centrifuges & Separators
• Industrial Piping
• Electrolysis Tanks
• Specialized Fittings

💎 Core Advantages

⚙️

Customized Service

Support for special specifications beyond conventional sizes. We offer laser cutting, water jet cutting, and technical support for welding processes.

✅

Quality Assurance

ISO9001 certified. Every batch includes a complete material report and supports optional third-party inspection reports upon request.

📦 Titanium Product Range

TITANIUM SHEET/PLATE

TITANIUM BAR/RODS

TITANIUM WIRE

TITANIUM TUBE/PIPE

TITANUM FOIL

TITANIUM BLOCK

TITANIUM BILLET

TITANIUM PROFILE

MACHINED PRODUCTS

❓ Frequently Asked Questions

What is Grade 7 Titanium?

Grade 7 Titanium is a titanium alloy created by adding a small amount of Palladium (0.12% to 0.25%). This addition significantly enhances its corrosion resistance, especially in reducing acids and localized chloride environments.

How does Grade 7 compare to Grade 2 Titanium?

While Grade 2 is commercially pure titanium with excellent formability, Grade 7 has nearly identical physical and mechanical properties but offers much higher resistance to crevice corrosion due to the palladium content.

Is Grade 7 Titanium easy to weld?

Yes, Grade 7 titanium has excellent weldability. Since it is essentially a dilute alloy, it behaves very similarly to pure titanium during the welding process, provided proper shielding gas is used.

What are the main applications for Grade 7 rods?

They are primarily used in chemical processing, brine handling, and pharmaceutical industries where equipment is exposed to chlorides, sulfides, and organic acids at high temperatures.

Can you provide custom lengths and sizes?

Yes, we support customization for specific diameters and lengths. We also provide precision processing services like CNC machining and specialized cutting to meet your exact project requirements.

What quality certifications are provided?

All products are ISO9001 certified. We provide a full Mill Test Report (MTR) with every shipment, detailing the chemical composition and mechanical properties of the specific batch.
