Suitable for ultra-low pressure precision molding.
Core Advantages: Good ductility (elongation 28%); no risk of brittle fracture; biocompatibility is better than other pure titanium grades and it is non-allergenic.
Suitable for low-pressure and high-cleanliness.
Core Advantages: Easy to clean; corrosion-resistant, no rust after long-term use; lower cost than alloy grades.
Suitable for high-pressure and harsh environment.
Core Advantages: Resistant to strong acids (such as hydrochloric acid and sulfuric acid), oil and gas corrosion, no leakage risk; resistant to vibration fatigue and long service life.
Suitable for Installation in Harsh Environments.
Core Advantages: The strength of the welded joint is more than 95% of the parent material and can be seamlessly welded into a piping system; it has excellent toughness in a -196℃ liquid nitrogen environment and has no cracking risk.
| Grade | Composition | Tensile Strength | Core Advantages | Applicable Scenarios |
|---|---|---|---|---|
| GR1 | Pure Titanium (≥99.6%) | 240MPa | Good plasticity, easy to bend and shape, smooth inner wall, and resistant to mild corrosion | Scenarios with low-pressure transportation and high cleanliness requirements |
| GR5 | Ti-6Al-4V | 895MPa | High strength, fatigue resistance, strong corrosion resistance | Scenarios with high pressure, harsh environment |
1. Applications of GR2 Titanium Capillary Tube
Food field: Aseptic feeding pipes for dairy product production lines and quantitative delivery pipes for beverage filling equipment, which meet hygiene standards.
2. Applications of GR5 Titanium Capillary Tube
Petrochemical Industry: Downhole high-pressure pressure gauge pipes for shale gas extraction, strong acid pipelines for refineries, and resistance to harsh environments.
Aviation Industry: Hydraulic oil pipelines for drone engines and satellite fuel lines, withstanding high and low temperature fluctuations.
